RP OPTIMA Industrial Male Plug 32A 2P+E 380V – 6h Position, IP44/IK08 & Screw Terminals

The RP OPTIMA industrial male plug delivers a rated current of 32A across 2P+E poles at 380V and 50Hz/60Hz frequency. Its 6h hour position complies with international standards and the splash-proof IP44 rating protects against water spray from any direction.

The technopolymer monobloc body resists impact at IK08 while the brass (CuZn) contacts ensure low-resistance connections. Screw terminals plus an external cable clamp deliver secure wiring for portable site use.

Key Features

• Rated current: 32A — heavy-duty industrial loads
• Poles: 2P+E with 6h hour position for 380V mains
• Protection: IP44 splash-proof, IK08 impact resistance
• Body: thermoplastic monobloc with screw terminals
• External cable clamp for strain relief

Product Benefits

• OPTIMA series engineered for portable, mobile industrial applications
• Brass (CuZn) contacts ensure stable, low-resistance current flow at 32A
• Grey-red two-tone body for clear voltage identification on site
• 50Hz/60Hz dual-frequency operation suits worldwide three-phase deployment
• Straight outlet style fits standard panel sockets and trailing leads

Technical Specifications

• Rated Current: 32A
• Poles: 2P+E
• Hour Position: 6h
• Rated Voltage: 380V
• Frequency: 50Hz/60Hz
• Protection: IP44 / IK08
• Mounting: Portable
• Outlet Type: Straight
• Terminals: Screw
• Contact Material: CuZn (brass)
• Body Material: Thermoplastic
• Colour: Grey - Red

Why You'll Love It

• Reliable OPTIMA build quality trusted on construction and industrial sites
• Splash-proof IP44 protection withstands outdoor and workshop conditions
• Screw terminals plus external cable clamp deliver fast, secure installation
• Package includes 1× RP Industrial Male Plug 32A 2P+E IP44
